Supplier TESCOM Pressure Regulator Valve 44-1115-24
WWW.DISTRIBUTORALATINDUSTRI.COM | Supplier TESCOM Pressure Regulator Valve 44-1115-24 | The TESCOM Model 44-1115-24 is a high-pressure, self-venting pressure reducing regulator designed for accurate and reliable control of gas pressure in industrial and instrumentation applications. As part of the TESCOM 44-1100 Series, this regulator utilizes a spring-loaded, piston-sensed design to reduce high inlet pressure to a stable and adjustable downstream pressure while maintaining excellent pressure control and shut-off performance. The self-venting feature automatically relieves excess downstream pressure to atmosphere whenever the outlet pressure setting is reduced, providing enhanced operational safety and simplified pressure adjustment. The regulator is suitable for clean, dry, non-corrosive gases and is widely used in gas distribution systems, calibration equipment, analytical instrumentation, laboratory gas supply, and high-pressure pneumatic systems.
Supplier TESCOM Pressure Regulator Valve 44-1115-24
Technical Specifications
| Parameter | Specification |
|---|---|
| Equipment | Pressure Regulator |
| Manufacturer | TESCOM Corporation (Emerson) |
| Series | 44-1100 Series |
| Model | 44-1115-24 |
| Type | Self-Venting Pressure Reducing Regulator |
| Operating Principle | Spring Loaded, Piston Sensed |
| Function | Reduces high inlet pressure to a stable and adjustable outlet pressure |
| Maximum Inlet Pressure | 6000 psig (414 bar) |
| Outlet Pressure Range | 25–4000 psig (1.7–276 bar) |
| Flow Coefficient (Cv) | 0.06 |
| Leakage | Bubble-Tight Shutoff |
| Proof Pressure | 150% of Maximum Rated Inlet Pressure |
| Operating Temperature | -34°C to 60°C (-30°F to 140°F) |
| Inlet Connection | 1/4 in. FNPT |
| Outlet Connection | 1/4 in. FNPT |
| Venting | Internal Self-Venting |
| Country of Origin | Made in U.S.A. |
Construction Materials
| Component | Material |
|---|---|
| Body | Brass |
| Bonnet | Brass |
| Piston | Stainless Steel |
| Valve Stem | Stainless Steel |
| Internal Components | 300 Series Stainless Steel |
| Main Valve Seat | Polyimide (Vespel®) |
| Relief Valve Seat | PCTFE |
| O-Rings | Buna-N (Nitrile) |
| Back-up Rings | PTFE |
| Inlet Filter | 40-Micron Bronze Filter |
Main Features
- High-pressure pressure reducing regulator for gas service.
- Spring-loaded, piston-sensed construction for accurate pressure regulation.
- Self-venting design automatically relieves downstream pressure when the outlet pressure setting is decreased.
- Bubble-tight shutoff minimizes internal leakage.
- Compact and rugged construction for industrial environments.
- Removable valve cartridge for simplified maintenance and servicing.
- Built-in inlet filter protects internal components from contamination.
- Standard FNPT threaded ports for easy installation.
- Excellent pressure stability under varying inlet pressure conditions.
- Suitable for continuous-duty industrial applications.
Working Principle
High-pressure gas enters the regulator through the inlet port and flows toward the valve assembly. The outlet pressure is controlled by balancing the spring force, adjusted through the top adjusting screw, against the downstream pressure acting on the piston. As the downstream pressure reaches the desired set point, the valve modulates automatically to maintain a constant outlet pressure. When the outlet pressure setting is reduced, the internal self-venting mechanism opens to release excess downstream pressure to atmosphere until the newly selected pressure is achieved.
Main Components
- Adjusting Screw
- Spring
- Bonnet
- Piston Assembly
- Main Valve
- Valve Stem
- Valve Seat
- Relief Valve
- Inlet Filter
- Regulator Body
- Inlet Port
- Outlet Port
- Gauge Ports
- Internal Vent Passage
- O-Ring Seals
Typical Applications
- Instrument Air Systems
- Nitrogen Distribution Systems
- Calibration Gas Panels
- Analytical Instrumentation
- Laboratory Gas Supply Systems
- Gas Cylinder Pressure Reduction
- Pneumatic Control Systems
- Pressure Test Benches
- Process Instrumentation
- Ground Support Equipment (GSE)
- Industrial Gas Distribution Panels
- High-Pressure Gas Control Systems
