Supplier Hattersley Check Valve 650 (Cast Iron)
WWW.DISTRIBUTORALATINDUSTRI.COM | Supplier Hattersley Check Valve 650 (Cast Iron) The valve is suitable for velocities of up to 3 metres per second and is ideal for use with water or other liquids. It features a bolted cover and can be mounted in both horizontal and vertical pipelines
Supplier Hattersley Check Valve 650 (Cast Iron)
The Hattersley Fig. 650 Check Valve (Cast Iron) is a robust non-return valve designed to prevent reverse flow and maintain unidirectional fluid movement in heating, cooling, HVAC, and water distribution systems. Manufactured from high-quality cast iron, the valve provides excellent durability, reliable performance, and a long service life in commercial and industrial applications.
The valve operates automatically using a swing check mechanism, allowing the disc to open when fluid flows in the intended direction and close automatically when reverse flow occurs. This design helps protect pumps, boilers, heat exchangers, and other equipment from damage caused by back pressure and water hammer.
Its low-pressure-loss characteristics ensure efficient system performance, while the sturdy construction makes it suitable for handling hot water, chilled water, and other non-aggressive fluids commonly used in building services and hydronic systems.
Key Features
- Heavy-duty cast iron body for strength and durability.
- Automatic swing check mechanism for reliable backflow prevention.
- Designed to maintain one-way flow and protect system equipment.
- Low-pressure-drop design for improved hydraulic efficiency.
- Suitable for hot water, chilled water, and non-aggressive fluids.
- Minimal maintenance requirements and long operational life.
- Flanged connections for secure and easy installation.
- Ideal for commercial and industrial building service applications.
Applications
- HVAC (Heating, Ventilation, and Air Conditioning) systems.
- Hot water and chilled water circulation systems.
- Commercial and industrial water distribution networks.
- Boiler and heat exchanger installations.
- Pump discharge lines and backflow prevention systems.
- General hydronic and utility service applications.
General Specifications
| Item | Specification |
|---|---|
| Brand | Hattersley |
| Model | Fig. 650 |
| Valve Type | Swing Check Valve (Non-Return Valve) |
| Body Material | Cast Iron |
| Disc Material | Cast Iron / Bronze Faced (depending on specification) |
| Seat Material | Metal Seat |
| Connection Type | Flanged |
| Operation | Automatic |
| Pressure Rating | PN16 |
| Maximum Working Temperature | Up to 120°C |
| Suitable Media | Hot Water, Chilled Water, and Non-Aggressive Fluids |
| Applications | HVAC, Water Distribution, and Building Services |
The Hattersley Fig. 650 Check Valve (Cast Iron) offers dependable backflow prevention, robust construction, and efficient operation, making it an ideal solution for protecting equipment and ensuring reliable fluid flow in modern hydronic and water management systems.
